Single Sheet Semi-auto High Speed stitcher
WS-2800A Semi-auto High Speed stitcher
Features
Semi-auto stitcher is a high speed operation and high efficiency of the nail molding cartons machine. It can promotes product output efficiency and expands the capacity, also provides more flexible production scheduling for the producer, and can saves time, materials and labor costs at the same time.
- Servo system Speeding semi-auto stitcher can nails 450 pcs per minute. It takes one minute to change size.
- The user interface is easy to operate, no training is necessary
- Single, double and fortified nail can be nailed at one time. It suits for different types of customers on the requirement of nails.
- Counter in the feeding part can set the number of the pack; the box will come out in pack.
- The bench adopts the automatical system to control the bench lifting and descending which can be automatically lifted and descended in accordance with the height of paper stacking.
- All the bearings from the important parts of the machine except the ball-bearing uses Japan brands, such as NSK etc.
- Operation interface
- A touch screen is set on the operation panel, can be predefined the ways of nailing, the volume of nail, and the data of production output, easy for operation
Feeding section
The four-shaft rubber roller feeding system and the structure of baffles of both sides horizontal aligning manual adjusted are adopted to make sure sheets can be feed smoothly and effectively and the accuracy of nailing position.
Adjustment Suction
The worm wheel lifting device structure, which provides 360 degree positive and negative of manual adjustment, is adopted to adjust the space of feeding roller and the pressure. It can adapt different material and thickness cardboard in both running and stop statuses, and makes sure the sheet can be feed smoothly and effectively. The adjustment can be made quickly and conveniently.
Electric appliance configuration
95%of the machine electrical elements use international famous brands. The control center uses TAIWAN PLC provides higher reliability and lower failure
The nail head
The subassembly of nail head are made from special steel through heat treatment and grinding. It’s efficient and endurable. It can highly promotes the speed of the blade and the bottom die are made from tungsten steel
